Jump Training Outlines

Expand all Collapse all

• The Jump #1 - The Hows & Whys of Template Construction

  Topics:

  Make Jump Start Run
      Our Goals and/or Your Goals - get the templates working
  Why and How the NCS Standards make your life easier
      Why the NCS and UDS make you productive
  Do Layers Really Matter?
       How to more easily manage the layer properties
      How and Why - Layers are Styles

  Those Pesky AutoCAD Details
      Textstyles to Annotate or Not
          Quick Change to AutoCAD Styles and for Fast Money
      Where and How to plug in your Linetypes - Use Design Center
      Where and How to plug in your Blocks - USe Design Center and Rename
  Why Jump Start is STB based
      How STB works differently than CTB
      How to get over it and get to work

  Sanity in the Civil 3D Toolspace
      Style, Set & Setting Essentials
      Basic JS Naming Conventions (Label Styles come later…)
      Do you start at the top? The Top of What?
      Drawing Settings
  The Hierarchy Rules
  The Simple Style Rules

• The Jump #2 - Style Essentials & Maintenance

   Topics:
  Point Styles & Point Label Styles
          Symbols/Markers in Point Styles
          Point Label Styles
          Description Key Sets
  The unique Surface Feature Styles
      The critical Display tab
      Counting the other tabs

  The Update Styles Process
      Open the template or drawing file with the styles you need
      Open the drawing you want to update
      Delete the old styles STARTING with SETS
      Make sure the drawing to update is the CURRENT drawing
          Tiled drawing Windows help
      Settings Tab
          Expand the Features tree for the Feature and Label Styles you need
          Select Styles at the lowest level in the tree and work uphill through the feature
          – Do SETS last
      Drag and Drop into the CURRENT Drawing
      Always Overwrite – you know these are RIGHT

  Basic Alignment, Profile, and Section Features
      The Linear Features
          Group Labels and basic labels

  The Basics of Label Sets
          What Sets collect
              Styles
              Properties

  Those Beastly Profile and Section Views
      Review of the View Features properties interface
      Own the Sets
      And maybe the Styles in them
      For Updates – Clear the Sets and Feature Settings FIRST



• The Jump #3 - Essentials of Label Styles and Sets

  Topics:
  The Collector Features in C3D
          Sites
          Point Groups
          Surfaces
          Grading Groups
          Parcels
          Corridors
          Assemblies
          Sample Line Groups
          Pipe Network Features
          More….
  Profile Views
      The publishing engine for profiles and pipe networks
      Label Sets make the annotation easier
      Labels anchor to the Feature or the View
      Labels have Extensions anchors
  Section Views
      The publishing engine for Sections
      Powered by a Sample Line Group collector
      Site Section and Road Sections are the same
      Sections employ multiple Styles and multiple Label Styles
      The General Multipurpose Styles drive the results

  How the General Multipurpose Styles connect to some Collectors
          Markers
          Feature Lines
          Links
          Shapes
          Code Sets
  Style collections for Corridors and Cross Sections
      What about Sites?
      Connect Feature Lines, Alignments, Parcels, Gradings and more…
      Control interactivity

  What to Do with Label Styles
      SAVE! SAVE! SAVE!
      Plan before you Play
          Playing with Label Styles eats man-hours
          Draw out what you want – Do a markup of a plan set
          Review the available Feature Data before you start
      Create healthy parent styles
          Decide on the components you need and make them
          Name the components appropriately
          Reduce the number of Text components to the minimum number you need
          The default “new” label style components names are NOT what you want
          Get the parent to work and do what you planned and STOP
      Resist Label Style Lust the urge to keep trying to do MORE

  What Not to Do with Label Styles
      Don’t add components to a child label style
      Add it to the parent FIRST and make it invisible
      Create new Parents to handle big differences
      Use parent names to organize purpose and use
      Try not to change the ORDER of how components are connected in a child style
          You may get away with this, but only if
          you obey the DO NOT ADD Rule
          you don’t change to parent
      Do not experiment with child styles under a working parent
          Make a copy of the parent and a new child and play there

• The Jump #4 - Maintain & Customize Jump Start

   Topics:
  Drawings in Civil 3D
       Drawings Start as Model drawings
       They become Data or Xrefs for other Model or Model (design) drawings
       Publish drawings are mostly references

  Drawing Types
    Model Drawings
       Need Styles at least based on Task and Features
    Xdata Drawings
       No Styles except perhaps to update
       Purge Styles and Layers Ruthlessly
    Xref Drawings – used to display and annotate the model
       Need Styles at least to Display Feature Content
       Purge before archiving
    Publish Drawings
       No Styles

  Code Set Styles
    What they do for Corridors
       Generate the Feature Line line work
       Corridor output can be used for more design
       Generate the Shape fills in Plan
    What they do for Sections
       Generate the cross section view line work and fills for subassemblies
       Generate the labels for the subassembly Shapes and Points

  Get Jump Start Working
    Evaluate and KISS
       Use the demo drawings to explore Styles for Key Features
       Do work with your data and unchanged styles
       The less you tweak the less work you have to do

  How to Rip and Tear
    Remove it if you don’t need it now
    It may exist for a good reason…but you can get it back
  Key Issues
    Colors to make IMPORTANT things familiar
    Linetypes to get your look at feel
    Create external Layer States files to restore your layer changes to
    supplied updates and project data drawings
    Edit and OWN the ONLY the Sets and most used Styles

  Feature Styles
      Graphically simple – most changes are to Layers

  Label Styles & Label Sets
      Fonts & Font Size
      Edit and OWN the most useful Label Sets
      Reduce the number of Label Styles in YOUR templates

  The Maintenance Plan Checklist
      Remember to PDCA (Plan Do Check Analyze)
      You must have a time frame or everything becomes an emergency and a crisis
      Don’t Fight fires Prevent fires
          It will never ALL get done at once
      Do a pass and STOP for a set period of time
      Document in writing what you changed
      Create one template that ONLY has your changes
      Do Work
      Document in writing what you think must change
          Updates are going to happen so how do you handle that?
      Remember – You choose

  The Style Update Process
      Make sure you have backups
         The update process will fail because of ID10T errors – we mess up
      Make the drawing to update “Current”
      Use Settings>>Master View
          The Labels Only view may help but don’t forget it does not show everything you may need to update
      Update from the other drawing
      Copy and/or Update Styles from the lowest level and branch in the Toolspace
      Parent Label Styles come over this way
      Do the Label Sets Last
      Be Bored and Systematic
      When in doubt OVERWRITE

  Make Template Updates Easier
      Start with the right ACAD template – stb
          We supply a NO STYLES template on the Updates page on cadpilot.com
      Purge the easy to identify “C” and “V” blocks
      Load the linetypes, hatch patterns, textstyles with Design Center from a
          copy of your good template after it is updated with changes
      Load YOUR blocks with Design Center
          Blocks should use NAMES in the Jump Start template OR
              be completely YOUR OWN – easiest to maintain.
          Don’t mix and try to match
      Layer State files make Layer updates easy
          Make sure they are EXTERNAL and read only
      Insert Exploded the new update template
          This will NOT overwrite YOUR changes
      Purge the Layers you KNOW you don’t want
          Purge ALL works as a Quick Fix
          All the layers are still in the Update template
      Tweak New Style Referenced layers and update your external Layer States files
      Update your OWN Styles & Sets into the drawing
      Evaluate the new styles that may help your OWN Sets and Styles and own and update them
      Rip and Tear
      Go back to work

  Data drawings are different from the drawings used to publish the model
      Data drawings have almost NO STYLES – Delete Styles
      Data drawings end up as references in Publish drawings

  Tell us what you Need
      Email us Style requests in writing
      Your Purpose and the Why are important information
          Please do not assume we understand
          It may already be in there but you may have missed it
      The kind of work you are doing is IMPORTANT too
      Show a picture of what you want if possible
  If it is Broken, please tell us
      If we don’t know, we may not fix it.
